MEAN WELL LED DRIVER LCM-60DA 500mA 600mA 900mA 1050mA 1400mA 60W DALI led driver

FOB Reference Price:Get Latest Price
  • 1 - 9
    US $31.42
  • 10 - 49
    US $29.76
  • 50 - 199
    US $27.66
  • >=200
    US $26.93
Supply Ability:
100000 Piece/Pieces per Month enough stocks for power supply
Port:
Shanghai, Ningbo or Guangzhou etc.
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Meanwell
Model Number:
LCM-60DA
Output Power:
60W
Output Type:
Multiple, Multiple
Input Voltage:
180 ~ 295VAC 254 ~ 417VDC
Output Voltage:
2-90V
Output Frequency:
0
Output Current:
500mA 600mA 700mA 900mA 1050mA 1400mA
Product Name:
60W DALI led dimming driver
Function:
Built-in 0~10Vdc and PWM signal dimming function
PFC:
yes
Certification:
CB UL CE TUV EMC ENEC
Protections:
Short circuit/Over temperature
Paking:
0.24Kg ; 54pcs/15Kg/1.12CUFT
Warranty:
3 years
Efficiency:
92%
Dimention:
123.5*81.5*23mm (L*W*H)
Packaging & Delivery
Packaging Details
Special Cartoon protective exporting power supply carton,Packing:0.24Kg ; 54pcs/15Kg/1.12CUFT; Dimension:123.5*81.5*23mm (L*W*H)
Delivery Time
Shipped in 5 days after payment
Power Adapter

MEAN WELL LED DRIVER LCM-60DA 500mA 600mA 900mA 1050mA 1400mA 60W DALI led dimming driver

Features:

1.Output current level selectable by DIP S.W.
2.Built-in active PFC function
3.Protections: Short circuit / Over temperature
4.Cooling by free air convection
5.Fully isolated plastic case
6.Class 2 power unit, no FG
7.Built-in 0~10Vdc and PWM signal dimming function
8.No load power consumption <1.2W(Note.7)
9.Power supplies synchronization function up to 10 units
10.3 years warranty

LCM series is a single unit supplies multiple current levels,350mA/500mA/600mA/700mA/900mA/1050mA. The current levels are able to be easily switched by adjusting the built-in switch. LCM switching power supply also provide the dimming function that is controlled by external 0-10VDC or PWM signal or resistance. Moreover, the synchronization design allows the dimming for up to 10 units of LCM led driver to be controlled. Differentiating from general DC output power suppliers, LCM series power supply built-in DALI interface and push dimming function for LCM-25DA/40DA/60DA, multiple-stage C.C. level selectable by DIP switch.


Once you’re found an Mean well LED driver, Kulon Electronics will make your Mean well placing order easy. These LED drivers suitable for indoor LED lighting, office LED lighting and LED decorative lighting. “Total quality assurance and customer satisfaction” are the central goals of our company.

Detailed Images
MODEL
LCM-60DA







Output
SELECTABLE CURRENT
  500mA
700mA
900mA
1050mA
1400mA
DC VOLTAGE
2 ~ 90V
2 ~ 86V
2 ~ 67V
2 ~ 57V
2 ~ 42V
RATED POWER
60.3W
RIPPLE & NOISE (max.)
700mVp-p
VOLTAGE ADJ. RANGE
95V
73V
SETUP, RISE TIME
500ms, 80ms / 230VAC at rated power
CURRENT
ACCURACY
±0.5%
HOLD UP TIME
16ms/230VAC at rated power
MODEL
LCM-60DA




INTPUT
VOLTAGE RANGE
180 ~ 295VAC 254 ~ 417VDC
FREQUENCY RANGE
47 ~ 63Hz
EFFICIENCY
92%
AC CURRENT
0.32A/230VAC 0.27A/277VAC
MODEL
LCM-60DA

PROTECTION
SHORT CIRCUIT
Constant current limiting, recovers automatically after fault condition is removed
OVER TEMPERATURE
Shut down o/p voltage, recovers automatically after temperature goes down



ENVIRONMENT
WORKING TEMP.
-30 ~ +60 (Please refer to "Derating Curve" section)
WORKING HUMIDITY
20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-40 ~ +80 , 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03% ℃ / (0 ~ 50 ℃ )
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes





Safety & EMC
UL8750, CSA C22.2 NO.250.0-08, ENEC EN61347-1, EN61347-2-13, EN62384 independent,GB19510.14,GB19510.1 approved
Comply with IEC62386-101,102,207
I/P-O/P:3.75KVAC ; I/P-DA :1.875KVAC ; O/P-DA :1.875KVAC
I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH
Compliance to EN55015, EN61000-3-2 Class C( 50% load) ; EN61000-3-3; GB17625.1,GB17743
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61547 light industry level (surge 2KV), criteria A
More Led Driver

LCM series LED Driver varied from 16-90W with PFC function.

1.Output power: 25W
2.105*68*23mm (L*W*H)
3.3 years warranty
4.188-277VAC only

1.Output power: 40W
2.123.5*81.5*23mm (L*W*H)
3.Built-in DALI interface and push dimming function

1.Output power:60W
2.123.5*81.5*23mm (L*W*H)
3.Built-in 3 in 1 dimming function

4.3 years warranty

1.Output power: 40-120W

2.High effciency up to 90%
3.5 years warranty

1.Output power: 30-60W

2.Optional dimming function

3.Low cost, 2 years warranty


1.Output power: 40-120W

2.Built-in 3 in 1 dimming function

3.5 years warranty

Packing & Delivery
Our Company
LED Driver FAQ

1. Does MW LED power supply allow adjustment of output voltage and current levels?
LED power supply comparison table to see which MW LED power supply allows for V/I adjustments. A suitable unit can be picked based on the type of adjustment required. For the allowed adjustment range, please refer to the spec sheet. Tuning of the voltage and current levels can be done through the built-in VRs/potentiometers. The VRs can be accessed through IoADJ and VoADJ holes after rubber stopper removal. After adjustments have been made, please make sure rate power is not exceeded and the rubber stoppers are properly reassembled.


2. Can an IP67 SPS with plastic case be used in outdoor?
Basically, an IP67 SPS can be used in an outdoor environment. But it must be installed within an enclosure which assures no permanent immersion into water and no direct sunlight.


3. There are so many MW dimming products. How can I make a choice? What are the pros and cons?
Ans:First, you have to know your Led lamp specification in order to screen out a suitable Led driver range (Wattage, Voltage, Max Current CC or CV). From those ranges, further check a compatible dimming function. You can find the pros and cons of Dimming Function in MW's  catalog.
